Intelligent High Load Automatic Plate Storage Warehouse

In the era of Industry 4.0 and smart manufacturing, material storage can no longer be an isolated, disconnected function. The Intelligent High Load Automatic Plate Storage Warehouse from Herochu represents a fundamental shift from passive storage to active inventory intelligence—a system that knows what it holds, where every sheet sits, and when each piece is scheduled to move to production.

Beyond Motorized Shelving: The Intelligence Layer

Herochu’s intelligent high load automatic plate storage warehouse is not merely motorized shelving. It is a storage and retrieval platform that transforms raw sheet inventory into an on-demand, high-density, high-precision supply chain that never sleeps. The system’s intelligence layer delivers capabilities that traditional storage methods cannot match:

Inventory visualization tracks every sheet by material type, gauge, dimensions, and precise location within the storage tower. Operators can see the complete inventory status at a glance through the 15-inch touchscreen interface.

Autonomous inventory management assigns storage locations based on configurable rules—material grade grouping, thickness segregation, or first-in-first-out sequencing—depending on how the plant wants its stock organized.

Real-time ERP integration pushes inventory updates to enterprise systems whenever material is added or removed, enabling accurate production scheduling and automated material reservations.

High Load Capacity and Flexible Configuration

The intelligent high load automatic plate storage warehouse is engineered to handle the demanding requirements of heavy manufacturing. Standard configurations support sheet dimensions from 1250mm x 2500mm up to 2000mm x 6000mm, with custom widths available for specialized applications.

Per-layer load capacities range from 3 tons to 5 tons standard, with customizable options up to 10 tons for extreme applications. The number of storage tiers scales from 8 to 13 floors standard, expandable up to 15 to 20 levels depending on facility ceiling height.

This flexibility enables the system to accommodate a wide range of materials:

• Stainless steel sheets of various gauges

• Aluminum plates and blanks

• Mild steel and carbon steel plates

• Pre-coated and surface-sensitive materials

• Coiled steel and pre-cut blanks

PLC Touch Control and User Experience

At the heart of every intelligent high load automatic plate storage warehouse sits a Siemens S7-1500 PLC and a 15-inch industrial HMI. This control architecture delivers an intuitive user experience that minimizes training requirements and reduces operational errors.

Operators can:

• Select programs with two taps on the touchscreen

• View real-time stock levels and material locations

• Call up automatic first-in-first-out retrieval rules

• Monitor system status and performance metrics

• Generate inventory reports and consumption data

The system’s user-friendly interface means even staff with minimal training can quickly master the operation, reducing onboarding time and operational disruptions.

Seamless ERP and MES Integration

The intelligent high load automatic plate storage warehouse communicates natively with ERP and MES layers, enabling automated material reservations, production scheduling based on available inventory, and real-time consumption reporting. This integration delivers several critical capabilities:

Automated material reservations ensure that materials are reserved for upcoming production orders, preventing stockouts and production delays.

Production scheduling optimization uses real-time inventory data to schedule jobs based on available materials, reducing setup times and changeover delays.

Consumption reporting automatically updates inventory records as materials are consumed, eliminating the manual data entry and reconciliation that plague traditional systems.

Traceability from receipt through consumption enables complete material genealogy, supporting quality management and regulatory compliance.

24/7 Unmanned Operation and Lights-Out Manufacturing

The intelligent high load automatic plate storage warehouse is engineered for continuous, unattended operation. Positioned between raw material intake and machining centers, the tower acts as a buffer, sorter, and sequencer—all in one.

For facilities pursuing lights-out manufacturing, the system provides:

• Automated feeding of laser cutters, CNC shears, and robotic bending lines

• Native compatibility with 6-axis robotic arms, vision systems, and AGVs

• 24/7 operation with minimal human intervention

• Unmanned material flow from storage to production

This automation capability delivers substantial operational benefits:

• Labor cost reduction of up to 70 percent

• Forklift traffic reduction of up to 70 percent

• Throughput increase of 40 to 60 percent for downstream equipment

• Material handling time reduction of up to 80 percent

Space Optimization and Facility Economics

By building vertically rather than horizontally, the intelligent high load automatic plate storage warehouse delivers space efficiency that transforms facility economics. The system stores over 60 tons of plates within less than 10 square meters of floor space.

This dramatic space savings enables facilities to:

• Reclaim valuable floor space for production equipment

• Reduce material handling distances and travel times

• Eliminate wide aisles required for forklift access

• Improve overall facility layout and material flow

• Delay or avoid costly facility expansion

Quality and Certification

Herochu’s intelligent high load automatic plate storage warehouse systems are CE and ISO 9001 certified. Manufactured in a 10,000-square-meter facility with full pre-shipment load testing and global on-site installation support, each system is validated to meet rigorous performance standards before delivery.

Herochu (Jinan Constant Storage Machinery Co., Ltd.) specializes in advanced intelligent storage and retrieval systems (AS/RS) and customized industrial racking for sheet metal processing and manufacturing facilities. By replacing hazardous, space-consuming floor stacking with vertical and automated warehousing, these systems maximize space utilization, accelerate production workflows, and minimize workplace risks.
