High Capacity (1000kg-10000kg) Automated Pipes Metal Storage System

The storage of long metal pipes and tubes presents unique challenges that differ significantly from general warehousing. Pipes are susceptible to bending, rolling, and surface damage, and their sheer length complicates handling and retrieval. Manufacturers of steel pipes, aluminum tubing, and structural hollow sections have traditionally resorted to expansive outdoor yards or inefficient low-rise indoor racks—approaches that fail to meet the demands of modern lean manufacturing.

The Herochu High Capacity Automated Pipes Metal Storage System addresses this specialized need by transforming chaotic pipe yards into structured, high-efficiency environments. This is not simply a racking unit; it is a fully automated, intelligent warehouse specifically designed to handle the physical properties and logistical demands of pipes and tubes up to 8000mm in length and beyond.

Exceptional Load Capacity for Heavy-Duty Applications

The Herochu High Capacity Automated Pipes Metal Storage System is engineered to handle the heaviest industrial loads. With load capacities ranging from 1000kg to 10,000kg per unit—and individual rack layers supporting 3 to 5 metric tons—this system handles everything from lightweight aluminum rods to dense steel rebar bundles with equal reliability.

The “heavy duty” designation is not marketing exaggeration. The Herochu HC-XG6053-6 model carries 3,000kg per level across five layers, while the HC-XG8055-8 and HC-XG8085-10 models step up to 5,000kg per level, sufficient for bundled seamless pipes and heavy structural tubes. Storage towers are engineered to resist flex under load, eliminating sagging shelves and the associated material damage.

Technical Specifications for Demanding Environments

The Herochu High Capacity Automated Pipes Metal Storage System is built to exacting specifications. Standard configurations support 6000mm material lengths, with customization available for bundles up to 8000mm or 12 meters. Each storage cell measures 600mm × 500mm, providing stable support for long profiles.

The number of storage floors is fully customizable, with standard configurations ranging from 8 to 13 levels based on facility ceiling height and inventory volume. Each grid cell is designed to evenly support long profiles and prevent sagging or warping over extended storage periods.

Motion is powered by a chain-driven transmission system operating along precision linear guide rails. Vertical lifting speed reaches 9 meters per minute, while inlet and outlet operations occur at 12 meters per minute. Positioning accuracy of ±2mm ensures smooth, precise material transfers without damage.

System Architecture and Components

The Herochu High Capacity Automated Pipes Metal Storage System consists of a comprehensive set of integrated components: a loading and unloading gantry system, profile material racks with customizable layers, material frames that securely hold single or bundled profiles, and precision linear guide rails paired with robust chain-driven transmission.

At the heart of the system is a robust gantry-type material warehouse structure that utilizes a sophisticated loading and unloading gantry system. This gantry is purpose-built to manage the unique geometry of long profiles, moving along a gantry mobile track that allows precise positioning over designated storage bays.

The lifting device incorporated in the gantry is engineered for heavy loads, ensuring that bundles of pipes are raised and lowered smoothly without abrupt movements that could cause damage. The entire operation is managed from a centralized console that provides full visibility and control over the storage and retrieval process.

Space Optimization and Cost Efficiency

By shifting from traditional horizontal storage to vertical, automated storage, the Herochu High Capacity Automated Pipes Metal Storage System resolves key operational bottlenecks in pipe logistics and material feeding. The system stacks materials vertically along a single shared gantry aisle, eliminating the wide access lanes required by traditional forklifts and reclaiming 50% to 80% of warehouse floor space.

This vertical density translates directly into cost savings. A single Herochu high capacity automated pipes metal storage installation can store up to 500 tonnes of mixed profiles within a footprint of approximately 200 square meters, assuming a standard 12-meter bar length and 10 storage levels. This density is achieved through a combination of narrow aisle design, vertical stacking, and the elimination of fixed aisles.

Zero-Damage Handling and Operational Safety

Automated gantry pickers eliminate the drag marks, drops, and collisions common in manual forklift and crane operations, preserving stock value for expensive alloy and seamless pipes. The system is fully integrated with PLC controllers and touchscreen interfaces, supporting 24/7 automated operation.

Built-in safety measures include real-time load monitoring and laser obstruction sensors that automatically halt operation during misalignments or overloads. These features protect both equipment and personnel, reducing workplace accidents and associated costs.

Certified Quality and Global Support

Every Herochu High Capacity Automated Pipes Metal Storage System carries CE, EU, and ISO 9001 certifications, reflecting the company’s commitment to meeting strict international standards for safety, performance, and quality. As a direct manufacturer with over 15 years of industry experience, Herochu offers comprehensive support including complimentary engineering design, customized configurations, on-site global installation, and full pre-shipment load testing.
