Heavy Duty Telescopic Cantilever Rack for Pipe Storage

Industrial pipe storage has long been plagued by a fundamental contradiction: the need to store long, heavy materials efficiently while maintaining quick, safe access. Floor stacking consumes vast square footage, creates safety hazards, and turns material retrieval into a labor-intensive treasure hunt. Static cantilever racks improve organization but still force operators to navigate around fixed arms that block access to rear inventory.

Herochu has engineered a solution that resolves this contradiction at its core. The Heavy Duty Telescopic Cantilever Rack for Pipe Storage represents a paradigm shift in how warehouses, metal service centers, and fabrication shops manage their pipe inventory. Rather than forcing materials into static configurations, this system brings the storage to the operator through full-extension telescopic arms that roll out 100% into the aisle.

Structural Foundation Built for Heavy Loads

Every Herochu telescopic cantilever rack begins with a robust steel framework designed to withstand the demands of continuous industrial use. The upright columns are available in heights ranging from 2000mm to 9000mm, accommodating facilities with varying ceiling clearances and storage density requirements. Column heights of 6000mm, 7000mm, and 9000mm enable vertical storage strategies that dramatically increase capacity per square foot of floor space.

The arm configuration offers exceptional flexibility. Standard arm lengths of 1000mm and 2000mm serve as the foundation, with custom extensions available up to 3000mm to accommodate wider pipe diameters and bundled loads. Each arm supports between 0.5 tons and 3.0 tons, depending on the specification, with per-layer load capacities that can be customized to match specific inventory profiles.

The interlocking fixed arm structure delivers strong anti-fatigue and anti-impact performance, resisting deformation and damage under long-term heavy loads. This structural integrity translates directly into extended service life and reduced maintenance costs over the operational lifetime of the rack.

Telescopic Technology That Transforms Access

The defining feature of Herochu’s heavy duty telescopic cantilever rack is its roll-out mechanism. Each tier of arms mounts on precision-ground rollers and hardened rails, allowing smooth extension and retraction even under full load. Operators can choose between manual hand crank operation or motorized electric drive, depending on throughput requirements and load weights.

The electric drive system operates on 380V 50Hz 3-phase power and delivers extension speeds of 0.1 to 0.2 meters per second. Touch screen and push-button dual controls provide flexible operation options, while the electric control system ensures safe, stable performance throughout thousands of cycles.

When extended, the cantilever arms expose the entire length of stored pipes to overhead cranes or hoists. This eliminates the need for operators to reach into deep rack structures or maneuver around obstructions, significantly reducing retrieval times and minimizing the risk of material damage during handling.

Space Optimization Through Intelligent Design

Traditional pipe storage methods require wide aisles for forklift access, consuming floor space that could otherwise generate revenue. Herochu’s telescopic cantilever rack changes this equation entirely. The ability to retract arms when not in use reduces the rack’s footprint by 40 to 60 percent, turning a 1500mm arm into a 600mm protrusion.

Narrow aisle requirements mean warehouses can pack more storage capacity into existing buildings. The vertical storage capability of column heights up to 9000mm further multiplies density, allowing facilities to store pipes in multiple tiers without sacrificing accessibility.

The system accommodates pipe materials from 3 meters to 12 meters in length, with customization available for virtually any dimension. This flexibility ensures that Herochu racks adapt to existing inventory rather than requiring inventory to adapt to the rack.

Surface Treatment and Durability

Industrial environments expose storage equipment to moisture, dust, chemicals, and physical impact. Herochu addresses these challenges through comprehensive surface protection. Powder coating and painted finishes are available in blue, black, or white, providing corrosion resistance while maintaining a professional appearance.

For telescopic mechanisms with moving parts, Herochu applies a two-layer protection system: zinc plating on all roller components and slides, plus a powder-coated finish on static structural elements. This combination prevents galling and corrosion while maintaining smooth extension even after years of dusty or humid operation.

Customization for Specific Requirements

No two pipe storage operations are identical. Herochu recognizes this reality and offers extensive customization across every parameter. The number of layers ranges from 2 to 6, with each layer height adjustable to match specific pipe diameters and stacking configurations. Extension length, column height, load capacity, and arm configuration can all be specified according to actual material dimensions and available space.

Double-sided and single-sided layouts provide additional configuration options. Double-sided racks maximize storage density in central aisle configurations, while single-sided designs work effectively against walls or in perimeter locations.

Industry Applications

The Heavy Duty Telescopic Cantilever Rack for Pipe Storage finds application across multiple industrial sectors. Machinery manufacturing facilities use these racks to organize steel tubing and hydraulic piping. Pipe and profile processing operations rely on them for efficient work-in-progress storage. Metal service centers depend on them for inventory management of carbon steel, stainless steel, and aluminum pipe stock.

Construction material suppliers, structural steel fabricators, and oilfield equipment manufacturers all benefit from the organized, accessible storage that Herochu telescopic cantilever racks provide.
