Heavy Duty Cantilever Rack for Steel Pipe & Profile Storage

Steel service centers and metal fabrication facilities face a persistent challenge: how to store long, heavy, and awkwardly shaped materials without wasting floor space or risking product damage. Herochu has engineered a purpose-built solution — the Heavy Duty Cantilever Rack for Steel Pipe & Profile Storage. This system is designed from the ground up to handle the unique demands of storing steel pipes, structural profiles, and extrusions in high-volume industrial environments.

Why Cantilever Design Makes Sense for Long Materials

Traditional pallet racking struggles with long materials. When you place 6-meter pipes or 12-meter profiles on standard beams, you either lose significant storage density or create dangerous overhang conditions. The cantilever design eliminates this problem entirely. With no front uprights obstructing the loading face, Herochu’s Heavy Duty Cantilever Rack allows forklifts and overhead cranes to access materials from the open side without interference.

This single-sided open face design is particularly valuable for steel distribution operations where aisle efficiency directly impacts throughput. Operators can approach the rack, lift a bundle, and withdraw it without maneuvering around structural obstacles. The result is faster cycle times, reduced product handling damage, and a safer working environment.

Robust Construction Built for Real-World Loads

At the core of every Herochu cantilever rack is a Q235B high-strength structural steel frame. This material grade is widely recognized in the steel industry for its excellent strength-to-weight ratio and weldability. The frame receives an electrostatic powder-coated finish that provides long-lasting protection against corrosion — a critical consideration for steel service centers where humidity and temperature fluctuations can accelerate rust formation.

Each cantilever arm is rated for 5000 kg and has been load-tested to 1.5 times its rated capacity. This safety factor ensures that even when handling heavy steel pipe bundles or dense profile stacks, the rack performs reliably. The dual-beam crossbar design distributes load evenly across the structure, reducing stress concentrations that could lead to premature fatigue.

Telescopic Arms Adapt to Varying Material Lengths

One of the most practical features of the Herochu Heavy Duty Cantilever Rack is its telescopic arm design. Arms extend from 400 mm to 800 mm in 100 mm increments, allowing operators to adjust the storage depth without replacing arms or modifying the rack structure. This flexibility is essential for facilities that handle mixed inventory — for example, a steel service center storing both 6-meter pipes and 7-meter profiles on the same rack system.

The telescopic mechanism is mechanically simple and robust. There are no hydraulic components or complex linkages that could fail under heavy loads. Adjustment can be performed quickly by maintenance staff, and the arms lock securely into position once set.

Independent Compartments for Organized Storage

Herochu’s cantilever rack features independent compartments on each tier and on both sides. This design allows for classified storage by material type, size, or customer order. In a busy metal fabrication factory, this organization reduces search time significantly. Instead of sorting through mixed bundles, workers can go directly to the compartment holding the required material.

The high load capacity of 3 to 5 tons per compartment means that even dense bundles of solid steel bars or thick-walled pipes can be stored without splitting loads across multiple locations. Customizable classification storage ensures that the rack can be tailored to the specific material mix of each facility.

Installation and Relocation Made Simple

The plug-in design of Herochu’s cantilever rack eliminates the need for on-site welding. Bolt-together modular construction means that two workers can assemble a standard bay in approximately four hours using basic hand tools. This rapid assembly is particularly valuable for facilities that need to reconfigure storage layouts as inventory patterns change.

Reinforced base plates with 20 mm anchor bolts provide maximum stability under full load. The floor-mounted design prevents tipping during loading and unloading, even when heavy bundles are placed on extended telescopic arms. Herochu supplies a detailed assembly manual and foundation drawing with every order, and the entire system is backed by a three-year structural warranty.

Technical Specifications at a Glance

Herochu offers multiple models to suit different pipe lengths and load requirements. The HC-G6053S and HC-G6053 handle 6000 mm pipes with a maximum load of 3000 kg per level. The HC-G9065 accommodates 9000 mm pipes at 5000 kg per level, while the HC-G12065 is designed for 12000 mm pipes at the same 5000 kg capacity. All models feature customizable layer counts, with five or six layers as standard. Clear space between levels is adjustable, with 600 mm as the default setting.

The dual-side mechanical assistance discharge method allows operators to load and unload from either side of the rack, further improving workflow flexibility. Galvanized steel cantilever arms enhance resistance to rust and wear, extending service life in demanding environments.

A Smart Investment for Steel Storage

For steel service centers, metal fabrication factories, and distribution operations, the Herochu Heavy Duty Cantilever Rack for Steel Pipe & Profile Storage represents a practical, durable, and flexible solution. Its combination of high load capacity, corrosion protection, and customizable configuration makes it a smart investment for any facility that handles long steel materials. With CE certification and ISO 9001 manufacturing standards, Herochu delivers a product that meets international quality expectations.
