Twin-tower Automatic Sheet Warehouse

Automation is the defining characteristic of the fourth industrial revolution, and the Herochu Twin-tower Automatic Sheet Warehouse is at the forefront of this movement. Traditional warehousing for sheet metal is labor-intensive, dangerous, and prone to human error. Herochu has redefined this process by creating a fully automated ecosystem where high-precision robotics and intelligent software manage the heavy lifting. This Twin-tower Automatic Sheet Warehouse is more than a storage rack; it is an autonomous logistics hub that operates with surgical precision, reducing manual handling to zero and ensuring that your production cycle is uninterrupted.

Superior Strength Through Analysis A Twin-tower Automatic Sheet Warehouse must handle thousands of cycles annually under heavy loads. To ensure these systems never fail, Herochu employs Simsolid and Ansys finite element stress analysis. This allows our design team to simulate the dynamic forces acting on the frame during high-speed lifting and horizontal movements. The warehouse body, composed of high-strength thick-walled steel, is verified for rigidity and strength before it ever reaches the factory floor. This rigorous engineering ensures that the 8 to 13 floors of material are supported by a structure that can handle the 3T to 5T load per layer with a significant safety margin.

Mechanical Specifications and Performance The Herochu Twin-tower Automatic Sheet Warehouse is engineered for high-velocity operations. The transmission mode utilizes a high-durability chain drive, enabling a vertical lifting speed of 9m/min. Horizontal material flow is even faster, with inlet and outlet speeds at 12m/min. These speeds are governed by a sophisticated PLC control system that manages the ramp-up and ramp-down of motors to prevent material shifting. The movement mode utilizes high-precision linear guide rails, which provide the smooth travel necessary for the robotic arms and AGV transfer systems to function at their peak. Whether you require a 3015mm or a 6020mm specification, Herochu provides a consistent performance profile across the entire product line.

The Power of Automated Access At the heart of the Herochu Twin-tower Automatic Sheet Warehouse is the automated access system. Equipped with high-precision robotic arms and an AGV transfer system, the warehouse eliminates the need for forklifts and manual labor in the storage area. This integration allows for a single material retrieval time of 10 seconds or less. By removing the “human factor,” the warehouse dramatically reduces the risk of accidents and material damage. The “one item, one code” RFID management system tracks each board through its entire lifecycle, providing a digital twin of your physical inventory. This level of transparency is essential for modern lean manufacturing environments where every second of downtime is measured in lost revenue.

Smart Monitoring and IoT Integration Intelligence is built into every layer of the Herochu Twin-tower Automatic Sheet Warehouse. Through the use of IoT sensors, the system provides real-time monitoring of material quantities and positions. Fault detection and alerting are automated; if a sensor detects a deviation in pallet positioning or a mechanical anomaly, the system notifies the operator immediately. Additionally, the warehouse features overweight steel plate detection and empty slot verification. This prevents the common warehouse error of attempting to store a material in an occupied or overloaded slot. By automating these checks, Herochu ensures a 60% increase in inventory turnover, keeping your production line lean and responsive.

Customization and Global Readiness Herochu understands that global manufacturers require localized solutions. Our PLC control systems come with default Chinese and English language settings, but we also offer region-specific language customization to ensure your local operators can interact with the system intuitively. The physical warehouse is also highly customizable. From the number of layers to the specific load-bearing capacity (up to 6 tons), Herochu builds the warehouse to fit your workflow. We even offer custom colors to match your facility’s aesthetic. The idler wheel design on the pallets, featuring roller tracks and positioning safety devices, ensures that even the most customized configurations operate with the same high level of reliability and safety.
