Customizable Industrial Pipe Storage Racking System (ASRS)

Off-the-shelf racking fits the rack, not the factory. Every pipe warehouse is different — different lengths, different bundle weights, different ceiling heights, different throughput — and a fixed configuration forces the operation to adapt to the equipment instead of the other way around. A customizable industrial pipe storage racking system (ASRS) inverts that relationship. The tower height, the number of racks, the bin grid, and the aisle layout are all set from your material list, and the modular architecture lets the system grow when the business does. This article explains the customization options, how the modular design works, and how to plan a system that scales.

What can be customized

The Herochu ASRS line starts from three standard models, but the word “standard” only describes the starting geometry. Every major dimension is adjustable at order time:

The result is a warehouse built around the inventory rather than a catalog drawing. A plant storing mostly six-meter pipe gets a compact six-meter configuration; a plant handling twelve-meter structural profiles gets deeper bins and a longer travel path. Both use the same gantry platform, the same PLC control, and the same linear guide rail and chain drive system, so customization does not mean one-off engineering risk.

How the modular architecture works

The system is organized into three layers that can be extended independently. The rack towers form the storage layer; adding racks means adding capacity without changing the control logic. The gantry and rails form the movement layer; they are sized for the full planned layout, so a future extension does not require re-engineering the drive. The PLC forms the control layer; in the Herochu implementation, bin maps are configured in software, which means new towers appear in the system as a configuration change, not a programming project.

This separation is what makes the phrase “customizable industrial pipe storage racking system” practical instead of promotional. Because each tower is an independent module with its own bin grid, a warehouse can start with six towers, prove the workflow, and add two more next year without stopping production. The gantry aisle is designed once, for the final footprint, and the towers fill in over time.

Tailoring the layout to your building

The physical constraints of the building drive the layout: available length for the gantry travel, ceiling height for the tower stack, and door positions for material flow. Herochu engineers the layout from those constraints, deciding how many towers fit the aisle, how many layers fit under the roof, and where the inlet and outlet stations should sit relative to the cutting or processing line. The 600 x 500 mm bin grid keeps the system flexible within each tower, so changes in the pipe diameter mix do not force a rack rebuild — the same bin that holds a bundle of 48 mm tubes can hold a bundle of 76 mm tubes.

Expanding when demand grows

The modular design pays off at the moment most racking systems become a problem: expansion. With a fixed rack, growth means buying new racking, clearing new floor space, and re-planning the flow. With the modular ASRS, growth means adding towers along the existing aisle and updating the bin map in the PLC. The gantry, the rails, and the control system are already in place; the incremental cost is the hardware, not the project. For warehouses that expect their material volumes to double within a few years, that expansion path is worth more than any single component on the price list.

Customization without losing the core benefits

It is worth stating what stays fixed even in a fully customized system. The gantry traveling speed remains 5–30 m/min and lifting speed 5–15 m/min, with ±2 mm repeatability. The drive remains chain transmission on linear guide rails. The safety package — laser sensors, real-time load monitoring, PLC interlocks — remains standard on every configuration. Customization changes geometry and capacity, not engineering quality. Buyers should be suspicious of suppliers who treat every change as a special project with special pricing; on a modular platform, changes to layers, racks, and bins are configuration choices.

FAQ

How long does a customized configuration take to deliver? Delivery depends on the layout complexity, but because the platform is modular, most configurations are assembled from standard tower and rail modules rather than built from scratch.

Can the system be expanded after installation? Yes. Towers can be added along the existing gantry aisle, and the PLC bin map is updated in software. The movement layer is sized for the final footprint from day one.

What pipe sizes can the bins handle? Standard models are configured for 6,000 mm and 8,000 mm pipes, with bins accepting loose or bundled material up to 12 meters in a customized layout.

Do customized options cost significantly more? No. Layers, rack count, and bin grid are configuration choices on the Herochu modular platform, not bespoke engineering, so the price scales with hardware rather than project fees.

Planning your custom pipe storage system

Begin with the three numbers that define any layout: maximum pipe length, maximum bundle weight, and the ceiling height available for stacking. Add your throughput target and expected growth over the next five years, and send the set to Herochu. The engineering team will return a tower configuration, a floor plan with inlet and outlet positions, and a cycle-time estimate — and, just as important, a clear path for adding capacity later. A customizable industrial pipe storage racking system (ASRS) should fit your building and your material list on day one, and your growth plan on day one thousand.
