Steel Metal PVC Pipes Heavy-Duty Telescopic Cantilever Shelf for Storage – Custom-Built by Herochu from $3,660 | CE UE ISO 9001 Certified
When steel, metal or PVC pipes start to overrun your warehouse, the ripple effects are immediate: lost floor space, slower picking, higher damage rates and escalating safety incidents. Herochu’s Heavy-Duty Telescopic Cantilever Shelf eliminates every one of these pain points in a single, fully engineered solution. Each rack is purpose-built to your exact workshop dimensions, carries globally-recognized CE, UE and ISO 9001 certification, and starts at only $3,660—an ROI-positive investment you can scale as demand grows.
Why Cantilever? Why Telescopic?
Unlike pallet rack beams that force pipes to sit on fixed levels, Herochu’s cantilever arms project clear of any frontal obstruction and adjust front-to-back on telescopic rails. The result:
• Instant single-operator loading/unloading for bundles up to 12 m long
• Zero vertical interference when sliding arms forward—ideal for overhead crane or side-loader handling
• Up to 30 % denser storage versus fixed-arm cantilever because every arm can be repositioned without tools
Engineering That Works as Hard as You Do
Frame & Uprights: Fabricated from Q355B structural steel, shot-blasted SA 2.5 and finished with a two-part epoxy-polyester powder coat rated for corrosion class C4. Uprights are punched on 100 mm centers to accept arms at any height.
Arms: 3 mm reinforced box-section arms fitted with telescopic rails rated at 1.5 t per arm. Replaceable HDPE sleeve caps protect polished or coated pipe surfaces.
Base & Bracing: Bolted moment frames with X-bracing eliminate sway under seismic or forklift impact loads. Pre-drilled footplates accept M20 chemical anchors.
Dynamic Options: Upgrade any bay with 24 V electric roller arms, chain conveyors or pop-up chain transfers for push-button pipe presentation.
Core Models—Start Here, Grow Anywhere
| Model | Safe Load per Layer | Max Pipe Length | Layers | Overall Footprint (L×W×H) | Access Side |
|---|---|---|---|---|---|
| HC-G6053D | 3 t | 6 m | 4 + 1 | 6 435 × 3 340 × 1 750 mm | Bilateral |
| HC-G9055S | 5 t | 9 m | 4 + 1 | 9 435 × 3 340 × 1 550 mm | Unilateral |
| HC-G9055D | 5 t | 9 m | 4 + 1 | 9 435 × 3 340 × 1 750 mm | Bilateral |
| HC-G12055D | 5 t | 12 m | 4 + 1 | 12 435 × 3 340 × 1 750 mm | Bilateral |
Every parameter—load rating, arm spacing, number of layers, layer height and drive type (manual or electric)—can be customized without minimum order penalties.
Proven Advantages for Your Operation
- Optimize Space Utilization
Telescopic arms let you pull inventory forward only when needed, doubling aisle density and freeing up to 40 % more floor area for value-added processes. - Accelerate Pick & Load Cycles
Color-coded arm labels and laser-etched SWL tags enable instant identification, cutting retrieval time and crane idle hours. - Enhance Safety & Compliance
A clean, elevated storage environment removes trip hazards and keeps pipes clear of forklift traffic. Integrated deformation indicators warn when an arm has been overloaded or impacted. - Protect Expensive Inventory
HDPE sleeves and adjustable side-stops prevent metal-to-metal contact, eliminating scratches, dents and coating damage that lead to costly re-work. - Future-Proof Flexibility
The modular bolt-together frame accepts additional bays, taller extensions or full automation retrofits at any time—no welding, no downtime.
Industry Applications
• Steel service centers storing API, ASTM or EN pipe
• Petrochemical plants managing high-pressure seamless pipe and PVC conduit
• Power-generation facilities handling insulated steam lines and cable trays
• Mechanical & HVAC contractors staging stainless, copper or PVC piping for fast-track projects
Installation & Support
Herochu delivers more than steel. We supply anchor layouts, 3-D step-by-step assembly animations and optional on-site supervision worldwide. All racks are covered by a 10-year structural warranty, lifetime parts availability and 24/7 multilingual technical support.
Get a Custom Layout & Quote in One Business Day
Send us a simple floor plan and inventory list; our application engineers will return a telescopic cantilever layout, load analysis and transparent quotation—often within hours. Whether you need a single 6 m bay or a fully automated 500-t pipe yard, Herochu’s Steel Metal PVC Pipes Heavy-Duty Telescopic Cantilever Shelf turns chaotic pipe storage into a precision, profit-driving operation.
Contact Herochu Company today and reclaim your warehouse one telescopic arm at a time.
