Compound Servo Swing Arm Handling Manipulator

Sheet Metal Material Handling Equipment | Sheet Metal and Steel Lifting Equipment

The Herochu Servo-Powered Swing Arm Sheet Metal Manipulator is a high-precision, servo-driven robotic arm designed for automated loading, unloading, and material handling in demanding industrial environments. Engineered for ±0.1mm repeatability, ultra-smooth motion, and quiet operation, this system is ideal for industries such as electronics, automotive, medical devices, and packaging.With CE, UE, and ISO 9001 certification, Herochu ensures reliable, high-performance automation that can be customized to fit any workshop layout, enhancing productivity while reducing labor costs.

Sheet Metal Material Handling Equipment | Sheet Metal and Steel Lifting Equipment

Advanced Automation for Sheet Metal & Steel Lifting Operations

With CE, UE, and ISO 9001 certification, Herochu ensures reliable, high-performance automation that can be customized to fit any workshop layout, enhancing productivity while reducing labor costs.

Why Choose Herochu’s Sheet Metal Material Handling Equipment?

1. Unmatched Precision & Speed

Servo motor control ensures ±0.1mm repeatability for ultra-accurate positioning.
120° smooth arm swing for fast, efficient material transfer.
High torque servo lifting mechanism for stable, vibration-free operation.

2. Robust & Intelligent Design

Modular assembly for easy installation, disassembly, and reconfiguration.
Heavy-duty, oil-resistant suction cups with individual control valves for secure gripping.
Original imported Omron CNC control system for seamless automation integration.

3. Enhanced Safety & Reliability

Emergency stop protection and automatic braking for operator safety.
Power outage safety system prevents accidental drops.
Pneumatic (SNS) and electrical systems ensure smooth, uninterrupted operation.

4. Cost-Effective Automation

Reduces manual labor while improving throughput.
Ergonomic handling minimizes fatigue and maximizes efficiency.
Low air consumption (1.5m³/min at 0.6-0.7Mpa) for energy-efficient performance.

Technical Specifications

Servo Swing Arm Handling Manipulator Models

Model	HC-R3015-500	HC-R3015-750	HC-R3015-1000	HC-R4020-500	HC-R4020-750
Max. Plate Thickness	8mm	12mm	20mm	8mm	12mm
Max. Feeding Width	3000×1500mm	4000×2000mm
Min. Feeding Width	1250×1000mm
Max. Load Capacity	300kg	500kg	1000kg	300kg	500kg
Number of Suction Cups	15	15	118	15	15
Suction Cup Diameter	150mm	200mm	250mm	150mm	200mm
Power Mode	Electric

General Performance Parameters

Repeatability: ±0.1mm
Arm Swing Angle: 120°
Air Consumption: 1.5m³/min
Air Pressure Requirement: 0.6–0.7Mpa
Control System: Omron CNC

Industries Served

Herochu’s sheet metal and steel lifting equipment is widely used in:
✔ Metal Sheet Fabrication – Precise handling of large steel plates.
✔ Automotive Manufacturing – Efficient loading/unloading for laser cutting and stamping.
✔ Electrical Cabinets & Enclosures – Safe transport of heavy panels.
✔ Kitchenware Production – Smooth handling of stainless steel sheets.
✔ Medical & Electronics – High-precision positioning for delicate materials.

Key Advantages Over Traditional Handling Methods

✅ Faster Cycle Times – Automated loading/unloading reduces downtime.
✅ Improved Workplace Safety – Eliminates manual lifting risks.
✅ Higher Accuracy – Servo control ensures precise placement.
✅ Space-Saving Design – Modular structure fits compact workshops.
✅ Customizable Solutions – Adaptable to different sheet sizes and weights.

Conclusion: Elevate Your Production with Herochu Automation

The Herochu Servo-Powered Swing Arm Sheet Metal Manipulator is the ultimate solution for automated material handling, offering precision, speed, and safety in industrial applications. Whether you need sheet metal lifting, laser cutting automation, or robotic loading/unloading, Herochu’s CE, UE, and ISO 9001 certified systems deliver unmatched performance.

Upgrade your production line today with Herochu’s cutting-edge automation technology – Contact us for a customized solution!

FAQ

Here are some frequently asked questions about our sheet metal racks and pipe storage solutions. We hope you find them helpful!

Q1: Can I request a custom size or color?
Absolutely. We offer complimentary design services and deliver efficient, tailored solutions to meet your specific requirements.

Q2: Are you a manufacturer or a distributor?
We are a direct manufacturer with over 15 years of industry experience and expertise.

Q3: Is there a minimum order quantity?
No. We welcome orders of any size, starting from a single unit.

Q4: How can I get detailed product information?
Click the “Get a Quote” button to receive product images, detailed specifications, and videos. Our team is always ready to assist.

Q5: How do I provide my storage rack requirements?
Simply share the type, dimensions, and quantity of materials you plan to store, along with any other specific needs. We will develop a professional storage solution for you. Alternatively, leave your contact details for a personalized consultation.

Q6: Do you offer automated loading systems or robotic arms?
Yes. We provide loading robotic arms and integrated loading/unloading systems tailored to your laser cutting machine’s table size and material handling method (e.g., board rack, exchange platform, or material warehouse). Contact us with your details for a customized proposal.

Q7: Do you provide on-site installation and debugging?
Yes. Our technicians can travel to your facility for installation and debugging, ensuring successful operation. We have served clients globally, including in the USA, South Korea, Russia, Qatar, Mexico, South Africa, Egypt, and Lebanon.

Q8: How do you ensure product quality?
Our quality assurance includes:

A team of over 40 technical engineers for professional debugging and support.
A dedicated quality control department compliant with ISO9001 standards.
CE certification for all exports.
Rigorous load testing before shipment to ensure structural safety and reliability.

Q9: Where is your factory located?
Our modern 10,000-square-meter manufacturing facility is located in Jiyang Industrial Park, Jinan, Shandong, China.

Q10: How can I evaluate your company’s capabilities?
We offer virtual video factory tours and warmly welcome on-site visits.

Q11: What does your company specialize in?
Jinan Constant Storage Machinery Manufacturing Co., Ltd. is a high-tech enterprise specializing in the R&D, production, sales, installation, and service of intelligent storage solutions. Our product range includes sheet material warehouses, drawer-style shelves, cantilever racks, servo manipulators, gantry loaders, and fully automated handling systems. Supported by a skilled technical team and advanced equipment, we are committed to delivering high-performance storage products and solutions to customers worldwide.
