Sheet metal material handling equipment

Standard solutions rarely fit perfectly. That’s why Herochu prioritizes customization. The 500kg Industrial Manipulator Arm is designed from the ground up to adapt to your specific workshop layout and application requirements

Sheet metal material handling equipment

Cantilever Length Flexibility: Choose between standard 3000mm or 4000mm cantilever lengths to achieve the optimal reach for your machines and workspace.
Custom Tooling & Fixtures: While supplied with a powerful vacuum lifting system, the arm can be adapted for mechanical grippers, specialized clamps, or other end-effectors tailored to your specific parts.
Workshop Integration: Herochu engineers can work with you to ensure seamless integration with your existing laser cutting machines, conveyors, workbenches, or other production equipment.
Precise Maneuverability: Enjoy smooth 0-220° rotation around the column and effortless horizontal movement along the cantilever beam via integrated sliders and pulleys. Operators gain exceptional control for positioning heavy loads with minimal effort.

Rigorous Standards: Your Assurance of Safety and Quality

Trust is paramount when handling heavy industrial loads. Herochu demonstrates its commitment to safety, performance, and international best practices through major certifications:

CE Certified: Complies with essential European health, safety, and environmental requirements, ensuring safe operation within the EU market.
UE Certified: (Likely referring to UKCA or similar, confirmation advised – often used interchangeably with CE in some contexts, but crucial for specific markets).
ISO 9001 Certified: Guarantees that Herochu’s design, manufacturing, and quality control processes meet the highest international standards for consistent product excellence and reliability.

Key Technical Specifications at a Glance:

Feature	500kg Model Specification
Lifting Capacity	500 kg
Column Height	3320 mm
Column OD	245 mm
Column Thickness	8 mm
Base OD	550 mm
Base Thickness	20 mm
Rotation Angle	0-220°
Main Beam	2000 mm (80×80 mm)
Cross Beam	1000 mm (50×50 mm)
Suction Cups	8 x 200 mm diameter
Cup Buffer Stroke	70 mm
Ball Valves	4
Cantilever Length Options	3000 mm or 4000 mm
Diagonal Tie Rods	Included per length option
Sliders	Included per length option
Small Pulley	1

Tangible Benefits for Your Bottom Line:

Dramatically Reduce Manual Handling Risks: Eliminate strenuous lifts, awkward postures, and potential for crushing injuries associated with moving heavy sheet metal.
Boost Productivity & Efficiency: Significantly decrease load/unload and positioning times for laser cutters and other machines. Operators handle loads faster and with less fatigue.
Enhance Product Quality: Prevent scratches, dents, and damage caused by dragging or improper manual handling, especially critical for finished surfaces like stainless steel or brass.
Improve Operator Ergonomics: Enable precise, controlled manipulation with minimal physical exertion, leading to a more comfortable and productive workforce.
Maximize Flexibility: The customizable design ensures the manipulator fits your existing workflow and adapts to future needs, protecting your investment.
Ensure Compliance & Peace of Mind: CE, UE, and ISO 9001 certifications provide documented evidence of safety and quality commitments.

FAQ

Here are some frequently asked questions about our sheet metal racks and pipe storage solutions. We hope you find them helpful!

Q1: Can I request a custom size or color?
Absolutely. We offer complimentary design services and deliver efficient, tailored solutions to meet your specific requirements.

Q2: Are you a manufacturer or a distributor?
We are a direct manufacturer with over 15 years of industry experience and expertise.

Q3: Is there a minimum order quantity?
No. We welcome orders of any size, starting from a single unit.

Q4: How can I get detailed product information?
Click the “Get a Quote” button to receive product images, detailed specifications, and videos. Our team is always ready to assist.

Q5: How do I provide my storage rack requirements?
Simply share the type, dimensions, and quantity of materials you plan to store, along with any other specific needs. We will develop a professional storage solution for you. Alternatively, leave your contact details for a personalized consultation.

Q6: Do you offer automated loading systems or robotic arms?
Yes. We provide loading robotic arms and integrated loading/unloading systems tailored to your laser cutting machine’s table size and material handling method (e.g., board rack, exchange platform, or material warehouse). Contact us with your details for a customized proposal.

Q7: Do you provide on-site installation and debugging?
Yes. Our technicians can travel to your facility for installation and debugging, ensuring successful operation. We have served clients globally, including in the USA, South Korea, Russia, Qatar, Mexico, South Africa, Egypt, and Lebanon.

Q8: How do you ensure product quality?
Our quality assurance includes:

A team of over 40 technical engineers for professional debugging and support.
A dedicated quality control department compliant with ISO9001 standards.
CE certification for all exports.
Rigorous load testing before shipment to ensure structural safety and reliability.

Q9: Where is your factory located?
Our modern 10,000-square-meter manufacturing facility is located in Jiyang Industrial Park, Jinan, Shandong, China.

Q10: How can I evaluate your company’s capabilities?
We offer virtual video factory tours and warmly welcome on-site visits.

Q11: What does your company specialize in?
Jinan Constant Storage Machinery Manufacturing Co., Ltd. is a high-tech enterprise specializing in the R&D, production, sales, installation, and service of intelligent storage solutions. Our product range includes sheet material warehouses, drawer-style shelves, cantilever racks, servo manipulators, gantry loaders, and fully automated handling systems. Supported by a skilled technical team and advanced equipment, we are committed to delivering high-performance storage products and solutions to customers worldwide.
