Manual Telescopic Cantilever Rack

Herochu Manual Telescopic Cantilever Rack: Precision Engineered for Accessible and Dense Long Material Storage

In the complex environment of industrial storage and workshop logistics, the efficient handling of lengthy materials remains a persistent and costly challenge. Standard shelving solutions force compromises between accessibility, storage density, and operational safety, often resulting in wasted space, damaged inventory, and inefficient labor usage. The Herochu Manual Telescopic Cantilever Rack has been specifically developed to resolve these conflicts through an intelligent and robust design. This system represents a significant advancement in manual storage technology, offering unparalleled control and space optimization for a diverse range of bulky items, from steel profiles and plastic tubing to wooden boards and structural components.

The defining operational characteristic of this rack is its manually extracted telescopic arm mechanism. Engineered for both performance and reliability, the system allows operators to roll out the fully loaded level load arms with a controlled and manageable effort. The core of this smooth operation lies in the precision-machined cross-toothed driveshaft, which features a non-slip surface to ensure a positive grip. This design guarantees controlled rotary and roll-off movements of the pushing arm, even when supporting the rack’s substantial load capacity of 1,000 kg per shelf. The mechanical advantage built into the system means that a single operator can safely and effectively manage the entire loading and unloading process, eliminating the need for multiple personnel or the complex maneuvering of motorized equipment in tight spaces.

This manual extraction capability directly translates into profound spatial and operational efficiencies. By facilitating easy and quick access using an existing hall crane, the system completely removes the necessity for wide aisles typically reserved for forklift trucks or other industrial vehicles. The ability to extract each arm fully, up to 100 percent of its depth, brings the entire stored load directly to the operator, ensuring no item is ever out of reach or requires risky retrieval methods. This space-saving design allows workshops to reclaim valuable square footage, transforming previously allocated aisle space into productive storage capacity or additional working area, thereby increasing the overall functional density of the facility.

The structural integrity of the Herochu Manual Telescopic Cantilever Rack is uncompromising. It is built around a special rotary and rigid construction that is designed to resist torsion and maintain alignment under dynamic loads. All moving parts are supported by high-quality ball bearings, which contribute to the smooth extension and retraction of the arms while ensuring long-term durability and reducing maintenance requirements. The individual structures, comprising at least two base structures and longitudinal binders in the standard version, are fabricated as completely welded and assembled units. This manufacturing approach guarantees exceptional strength and stability from the moment of installation, providing a dependable storage asset for years of demanding service.

Flexibility is a cornerstone of the system’s design. It can be seamlessly adapted to the unique demands of any workshop. For high-level storage, goods can be safely accessed with the use of platform ladders or lifts. The management of residual lengths and offcuts is streamlined; they can be neatly organized using supporting pallets within the rack, or the shelf arm spacing can be custom-set to accommodate specific material dimensions, drastically reducing waste and disorganization. The standard configuration is finished in a structure blue (RAL 5012) with red roll-out arms (RAL 2002), but custom dimensions and paint coats in all RAL colours are available upon request to meet corporate branding or specific environmental coding needs.

To further enhance organizational capability, a comprehensive range of accessories is available. Compartment divider strips can be variably adapted to create distinct compartments within a single shelf level, perfect for the sensible organization of different long materials. These dividers, available in both hot-dip galvanized and electrogalvanized finishes, feature multiple perforations for flexible positioning. For applications requiring maximum adaptability, infinitely adjustable compartment dividers with square tube stanchions can be mounted directly onto the support profile, allowing for instantaneous reconfiguration to suit changing inventory profiles. Additional accessories include trays and boxes for organizing leftover pieces and the option to upgrade to electrically driven roll-out shelves should operational requirements evolve.

The system is available in several proven standard configurations, each designed to meet common industrial demands:

• Model HC-G6053D: 6m length, 3t load per layer, 4+1 layers (Bilateral assistance), 6435x3340x1750mm overall dimensions.

• Model HC-G9055S: 9m length, 5t load per layer, 4+1 layers (Unilateral assistance), 9435x3340x1550mm overall dimensions.

• Model HC-G9055D: 9m length, 5t load per layer, 4+1 layers (Bilateral assistance), 9435x3340x1750mm overall dimensions.

• Model HC-G12055D: 12m length, 5t load per layer, 4+1 layers (Bilateral assistance), 12435x3340x1750mm overall dimensions.

It is important to note that these specifications serve as a baseline. The load-bearing capacity, overall length, number of layers, and individual layer height can all be extensively customized to create a tailor-made solution for any specific application. Furthermore, the system is designed with future needs in mind; while optimized for manual operation, it can be specified from the outset or later retrofitted with electric drive components.

Manufactured under the rigorous protocols of CE, EU, and ISO 9001 certifications, the Herochu Manual Telescopic Cantilever Rack meets the highest international standards for quality, safety, and performance. It is the definitive choice for businesses seeking to optimize their long material storage through a system that masterfully balances human operation with mechanical advantage. Customizable solutions begin at $2,998. We encourage you to contact our engineering team to discuss a configuration that will transform the storage efficiency and operational workflow within your workshop.
