Herochu Laser Cutting Machine Loading and Unloading System: Automate Your Sheet Metal Production with Certified, Customizable Efficiency
In the high-stakes world of sheet metal fabrication, laser cutting is the backbone of precision—but even the most advanced laser cutter can’t reach its full potential without a seamless loading and unloading process. Manual material handling here means wasted time, increased labor costs, inconsistent workflow, and heightened risk of workpiece damage or operator injury. Herochu, a leader in industrial automation solutions, solves these pain points with its Laser Cutting Machine Loading and Unloading System—a fully integrated, CE, UE, and ISO 9001 certified solution designed to turn your laser cutting setup into a 24/7 automatic production unit. Whether you’re scaling up a small workshop or optimizing a large-scale factory, this system eliminates bottlenecks, boosts productivity, and adapts to your unique space—all with customizable pricing starting at $17,999.
Why Herochu’s Laser Cutting Loading and Unloading System? Certifications & Reliability You Can Trust
When investing in automation, quality and compliance are non-negotiable—and Herochu’s system exceeds global standards. It holds CE, UE, and ISO 9001 certifications, ensuring adherence to strict European safety regulations, environmental guidelines, and rigorous quality management protocols. For manufacturers operating in the EU, North America, or Asia, this means zero regulatory headaches: the system integrates seamlessly with existing laser cutters (regardless of brand) and aligns with local industry requirements. Every component—from the gantry truss to the PLC control system—is engineered for durability, with high-grade steel frames, corrosion-resistant finishes, and wear-resistant moving parts that stand up to the demands of daily heavy use. This isn’t just a “add-on” accessory; it’s a long-term investment in consistent, reliable performance.
System Composition: A Fully Integrated Automatic Production Unit
Herochu’s Laser Cutting MachineLoading and Unloading System isn’t a single tool—it’s a cohesive ecosystem of components working in perfect sync to handle every step of material flow, from storage to sorting. Here’s what makes up this game-changing setup:
Three-Dimensional Storage Warehouse: Acts as the “backbone” of the system, providing centralized, space-saving storage for raw metal sheets. With configurable floor counts (8–13 layers) and per-layer loads of 3T or 5T, it eliminates messy, floor-based material piles and ensures easy access to raw materials.
Double-Sided Gantry Truss: The system’s “transport highway,” offering stable, high-precision horizontal movement for loading and unloading manipulators. Its rigid structure minimizes vibration, ensuring that even heavy plates (up to 3000kg) are moved smoothly—critical for avoiding scratches or misalignment.
Loading & Unloading Truss Manipulators: Purpose-built for laser cutting workflows. The loading manipulator uses high-torque suction cups to lift and position raw sheets, while the unloading manipulator features durable forks to handle both finished products and scrap. Both operate with sub-millimeter precision, guided by the PLC control system.
Double-Layer Finished Material Truck: A mobile storage solution for post-cut materials, keeping finished products organized and separate from scrap to streamline sorting. Its double-layer design maximizes space efficiency, even in compact workshops.
PLC Control System: The “brain” of the operation. This intuitive, user-friendly system automates every step of the workflow—from triggering material retrieval to coordinating manipulator movements—with minimal human input. Operators can easily adjust parameters (e.g., plate size, cycle time) via a touchscreen interface, and the system logs real-time data for performance tracking.
Seamless Laser Cutter Integration: Designed to work with all major laser cutter brands and models. It syncs with your laser cutter’s exchange table, ensuring that loading and unloading happen in perfect timing with cutting cycles—no more waiting for manual material swaps.
Technical Specifications: Tailored to Your Production Needs
Herochu understands that laser cutting operations vary widely—from small shops cutting 3015mm sheets to large factories handling 6025mm plates. That’s why the system is available in multiple size configurations, with specs optimized for different workloads. Below is a breakdown of key technical parameters to help you find the right fit:
Specification Category
Details
Compatible Sheet Sizes
3015mm, 4015mm, 4020mm, 6015mm, 6020mm, 6025mm (covers most industry standards)
Storage Warehouse Floors
8–13 layers (configurable based on workshop height)
Per-Layer Load Capacity
3T or 5T (supports heavy raw material batches)
Maximum Plate Weight
300KG–3000KG (handles thin aluminum sheets to thick steel plates)
Air Consumption
1.5m³/min (efficient pneumatic operation for suction cups/forks)
Air Source Requirement
0.6–0.7Mpa (works with standard factory compressed air systems)
Control System
PLC with touchscreen interface (easy parameter adjustment, real-time monitoring)
Power Supply
380V/50Hz (compatible with global industrial power standards)
These specs aren’t just numbers—they translate to real-world flexibility. For example, a 6025mm system with 13 storage layers can hold enough raw material to run 8-hour shifts without reloading, while a 3015mm system with 8 layers fits perfectly in small workshops with limited vertical space. The 300KG–3000KG weight range means the system works for everything from automotive body panels to heavy structural steel—no need to invest in multiple handling solutions.
Step-by-Step Workflow: How the System Eliminates Manual Work
The true power of Herochu’s Laser Cutting Machine Loading and Unloading System lies in its seamless, automated workflow. Every step is designed to minimize human intervention, reduce cycle times, and eliminate errors. Here’s a detailed breakdown of how it operates:
1. Plate Delivery to Loading Station
Raw metal sheets start in the three-dimensional storage warehouse. The electric raw material trolley—guided by the PLC system—retrieves a stack of plates from the warehouse and transports them to the loading station, where it stops precisely (within ±2mm accuracy). This eliminates manual forklift trips, reducing the risk of collisions and material damage.
2. Suction Cup Loading: Precision Lifting & Positioning
The loading truss manipulator moves horizontally to the loading station via the double-sided gantry truss. Its suction cups (optimized for different plate materials, from aluminum to stainless steel) descend, create a strong vacuum seal, and lift a single plate—even if sheets are stacked tightly. A built-in “sheet separation” feature ensures no double-loading (a common cause of laser cutting errors). The manipulator then rises to a pre-set height (adjustable via the PLC), moves horizontally above the laser cutter’s exchange table, and descends to a designated position. The suction cups release the plate gently, and the manipulator returns to its starting position—all in under 60 seconds—to await the next loading command.
3. Laser Cutting: Syncing with Your Cutter
Once the plate is in place, the laser cutter’s exchange table (integrated with the system) moves into the machine’s processing area. The PLC system communicates with the laser cutter to confirm plate position, ensuring alignment with cutting patterns. After cutting is complete, the exchange table exits the processing area—triggering the next step in the workflow automatically.
4. Mobile Trolley Positioning for Unloading
While the laser cutter works, the double-layer finished material truck (mobile trolley) travels along its track to the unloading station, stopping precisely under the unloading manipulator. The trolley carries an empty pallet, ready to receive finished products and scrap—no manual positioning required.
The unloading truss manipulator moves horizontally above the exchange table. Its forks open, slide under the finished sheet and scrap (the system can be programmed to separate them if needed), and close securely. The manipulator rises to a fixed height, moves to the mobile trolley, and descends to deposit the materials. The forks open to release the load, then close as the manipulator returns to its starting position—ready for the next cycle.
6. Centralized Sorting: Streamlining Post-Cut Work
Once the mobile trolley is loaded, it exits the unloading area and moves to a designated sorting zone. A forklift or crane (coordinated via the PLC system to avoid bottlenecks) then transports the finished products and scrap to a manual sorting station. This keeps the laser cutting area clear and ensures that sorting happens away from the production line—further boosting efficiency.
Customization: Built for Your Workshop, Starting at $17,999
No two laser cutting workshops are the same—and Herochu doesn’t believe in one-size-fits-all automation. The Laser Cutting Machine Loading and Unloading System is fully customizable to match your space, workflow, and material needs. Here are just a few ways we tailor the system:
Size Adjustments: Modify the gantry truss length or storage warehouse dimensions to fit tight spaces or large factories.
Material Compatibility: Add specialized suction cups (e.g., for coated sheets) or reinforced forks (for extra-heavy plates) based on your materials.
Integration with Existing Equipment: Sync the system with your current laser cutter, ERP software, or MES (Manufacturing Execution System) for end-to-end production tracking.
Extra Features: Add optional components like automatic sheet cleaning (to remove dust before cutting) or scrap compaction (to reduce waste volume).
Best of all, customization doesn’t come with a prohibitive price tag. Herochu’s customized solutions start at just $17,999—a fraction of the cost of building a custom system from scratch, and a small investment compared to the long-term savings in labor and efficiency.
Who Benefits Most from This System?
Herochu’s Laser Cutting Machine Loading and Unloading System is a game-changer for any business relying on laser cutting—from niche fabricators to large-scale manufacturers:
Automotive Suppliers: Handle high-volume, consistent cuts for body panels or chassis parts without manual labor.
Metal Fabricators: Reduce lead times for custom orders by eliminating loading/unloading delays.
HVAC Manufacturers: Streamline production of ductwork and metal components, even with varying sheet sizes.
Aerospace & Defense: Ensure precision handling of high-tolerance, expensive metal sheets (no scratches or misalignment).
Electronics Manufacturers: Handle thin, delicate sheets for enclosures or components with gentle suction cup technology.
Why Choose Herochu Over Competitors?
When you invest in Herochu’s system, you’re not just buying equipment—you’re partnering with a brand that prioritizes your success:
Proven Reliability: CE/UE/ISO 9001 certifications and rigorous testing mean minimal downtime.
Local Support: Our global network of technicians provides installation, training, and maintenance—so you’re never left waiting for help.
Scalability: The system can be upgraded (e.g., adding more storage layers) as your business grows.
ROI Focus: Most customers see a return on investment within 12–18 months, thanks to reduced labor costs and increased production output.
Ready to Automate Your Laser Cutting Workflow?
If manual loading and unloading are holding back your laser cutting operation, it’s time to upgrade to Herochu’s Laser Cutting Machine Loading and Unloading System. With its certified design, seamless workflow, customizable options, and competitive pricing (starting at $17,999), this system turns your laser cutter into a fully automated production powerhouse—saving time, reducing costs, and eliminating risk.
Contact Herochu today to schedule a virtual demo, discuss your workshop’s unique needs, or request a custom quote. Let’s build an automation solution that grows with your business—and helps you stay ahead of the competition.
