Heavy Duty Cantilever Rack for Long Pipe Storage

In industrial and construction supply warehouses, managing long, heavy materials like steel pipes, aluminum bars, or timber beams presents a unique logistical challenge. Traditional pallet racking systems often fail to accommodate these irregularly shaped items efficiently, leading to wasted floor space, unsafe stacking, and reduced operational throughput. Enter the Heavy Duty Cantilever Rack for Long Pipe Storage—a purpose-built solution engineered for high-capacity, organized, and safe storage of elongated goods.

Heavy Duty Cantilever Rack for Long Pipe Storage

Herochu’s HC-6016S model stands out as a premium example of this category. Constructed from high-grade Q235 carbon steel, this cantilever rack system combines structural integrity with intelligent design to support up to 8 metric tons per level—far exceeding standard industry expectations. With six adjustable levels and arms extending up to 2.5 meters, it is specifically optimized for storing pipes ranging from small-diameter conduits to large structural tubes.

Unlike conventional racks that require wide aisles for forklift maneuvering, the cantilever design eliminates the need for front obstructions. Each arm projects horizontally from a central column, allowing materials to be loaded and retrieved from the side or end without interference. This configuration not only enhances accessibility but also dramatically improves space utilization—a critical advantage in urban or cost-constrained warehouse environments.

The HC-6016S features double-sided or single-sided layouts, offering flexibility based on your facility’s traffic flow and inventory volume. Arms are available in 600mm or 800mm lengths and can be adjusted in 100–150mm increments vertically, ensuring precise alignment with varying pipe diameters. A slight 2° upward tilt on each arm prevents stored items from rolling off, while optional end-stops add an extra layer of safety.

Surface treatment includes epoxy electrostatic powder coating, which provides excellent corrosion resistance and durability—even in humid or outdoor conditions. Available in standard colors like blue, black, or white, the rack can also be customized to match corporate branding or safety coding systems.

Installation is straightforward via bolted assembly, requiring no welding and minimizing downtime during setup. The entire system is CE and ISO certified, guaranteeing compliance with international safety and quality standards.

Industries such as mechanical manufacturing, plumbing supply, steel distribution, and building materials retail rely on this system to streamline operations. Forklift operators can load multiple pipes in a single pass, reducing handling time by up to 40%. Moreover, the open design offers unobstructed visibility, simplifying inventory audits and reducing misplacement errors.

For warehouses seeking a scalable, robust, and future-proof storage solution for long materials, the Heavy Duty Cantilever Rack for Long Pipe Storage from Herochu delivers unmatched performance. Whether you’re storing 10-foot PVC pipes or 20-foot steel I-beams, this system ensures every inch of vertical space is used intelligently—without compromising safety or efficiency.

FAQ

Here are some frequently asked questions about our sheet metal racks and pipe storage solutions. We hope you find them helpful!

Q1: Can I request a custom size or color?
Absolutely. We offer complimentary design services and deliver efficient, tailored solutions to meet your specific requirements.

Q2: Are you a manufacturer or a distributor?
We are a direct manufacturer with over 15 years of industry experience and expertise.

Q3: Is there a minimum order quantity?
No. We welcome orders of any size, starting from a single unit.

Q4: How can I get detailed product information?
Click the “Get a Quote” button to receive product images, detailed specifications, and videos. Our team is always ready to assist.

Q5: How do I provide my storage rack requirements?
Simply share the type, dimensions, and quantity of materials you plan to store, along with any other specific needs. We will develop a professional storage solution for you. Alternatively, leave your contact details for a personalized consultation.

Q6: Do you offer automated loading systems or robotic arms?
Yes. We provide loading robotic arms and integrated loading/unloading systems tailored to your laser cutting machine’s table size and material handling method (e.g., board rack, exchange platform, or material warehouse). Contact us with your details for a customized proposal.

Q7: Do you provide on-site installation and debugging?
Yes. Our technicians can travel to your facility for installation and debugging, ensuring successful operation. We have served clients globally, including in the USA, South Korea, Russia, Qatar, Mexico, South Africa, Egypt, and Lebanon.

Q8: How do you ensure product quality?
Our quality assurance includes:

A team of over 40 technical engineers for professional debugging and support.
A dedicated quality control department compliant with ISO9001 standards.
CE certification for all exports.
Rigorous load testing before shipment to ensure structural safety and reliability.

Q9: Where is your factory located?
Our modern 10,000-square-meter manufacturing facility is located in Jiyang Industrial Park, Jinan, Shandong, China.

Q10: How can I evaluate your company’s capabilities?
We offer virtual video factory tours and warmly welcome on-site visits.

Q11: What does your company specialize in?
Jinan Constant Storage Machinery Manufacturing Co., Ltd. is a high-tech enterprise specializing in the R&D, production, sales, installation, and service of intelligent storage solutions. Our product range includes sheet material warehouses, drawer-style shelves, cantilever racks, servo manipulators, gantry loaders, and fully automated handling systems. Supported by a skilled technical team and advanced equipment, we are committed to delivering high-performance storage products and solutions to customers worldwide.
