Crank-Out Cantilever Pipe Storage System：Smart Steel Storage Solution
Herochu Crank-Out Cantilever Pipe Storage System: Maximizing Workshop Efficiency with Smart Steel Storage
Engineered for Heavy-Duty Industrial Applications
The Herochu Crank-Out Cantilever Pipe Storage System revolutionizes long-material storage with its patented roll-out mechanism. Designed for durability and precision, this CE/UE-certified, ISO 9001-compliant solution handles loads up to 5 tons per layer, accommodating pipes (steel, plastic), round bars, timber, and extruded profiles up to 12 meters in length. Its crank-operated arms extend fully for frictionless loading, eliminating manual lifting hazards while doubling operational speed compared to static racks.
Space-Optimized & Worker-Centric Design
-
Dynamic Space Utilization
- Arms retract to 0.5m footprint when idle, reclaiming 40% floor space vs. conventional cantilever racks.
- Modular 4+1 layer configurations (3 roll-out + 1 fixed top) adapt to ceiling heights from 1.5m to 2.5m.
-
Ergonomic Operation
- One-person operation reduces labor costs by 60% (field-tested in 200+ global installations).
- Smooth-rolling bearings require <15N effort for arm extension, enabling 30% faster cycle times.
-
Enhanced Safety Standards
- Reinforced steel arms with anti-slip channels prevent material displacement.
- Optional electric motorization (24V DC) reduces physical strain for high-frequency operations.
Customizable Specifications for Diverse Needs
| Model | Capacity | Max Length | Configuration | Dimensions (mm) |
|---|---|---|---|---|
| HC-G6053D | 3t/layer | 6m | Bilateral 4+1 | 6435×3340×1750 |
| HC-G9055S | 5t/layer | 9m | Unilateral 4+1 | 9435×3340×1550 |
| HC-G12055D | 5t/layer | 12m | Bilateral 4+1 | 12435×3340×1750 |
Tailored Solutions:
- Load capacity adjustable from 1.5t to 8t per layer via crossbeam reinforcement.
- Arm lengths customizable in 0.5m increments (max 14m).
- Galvanized or powder-coated finishes for corrosion resistance.
Why Choose Herochu?
- Proven Reliability: 15-year industry experience with installations in automotive, construction, and manufacturing sectors.
- Lifecycle Support: 3-year structural warranty + 24/7 technical assistance.
- Sustainable Design: 95% recyclable steel components align with LEED certification goals.
Ideal For:
- Pipe distributors requiring high-density storage
- Fabrication shops with mixed-length material handling
- Logistics hubs optimizing pallet-free transport
Pricing: Starting at $6,200 for standard configurations. Bulk order discounts available for 10+ units. Contact our engineers for a free site assessment and 3D layout simulation.
