Herochu Crank-Out Cantilever Warehouse Racks—Pipe Storage Rack Engineered for the Long Run
Specification
| Specifications | Load (single layer) | Size | Layers | Overall dimensions |
| HC-G6053D | 3t | 6m | 4+1(Bilateral assistance) | 6435x3340x1750mm |
| HC-G9055S | 5t | 9m | 4+1(Unilateral assistance) | 9435x3340x1550mm |
| HC-G9055D | 5t | 9m | 4+1(Bilateral assistance) | 9435x3340x1750mm |
| HC-G12055D | 5t | 12m | 4+1(Bilateral assistance) | 12435x3340x1750mm |
| Note: Both manual and electric can be customized, and the load-bearing capacity, length, number of layers, and layer height can be customized. | ||||
When long, unwieldy loads threaten to swallow floor space and slow your crew to a crawl, Herochu’s crank-out cantilever warehouse racks transform the challenge into an organized, revenue-generating workflow. Designed exclusively for facilities that handle steel pipe, PVC conduit, aluminum tubing, timber, or any other elongated stock, this roll-out cantilever rack system retracts and extends with a smooth turn of the crank, giving you aisle-wide clearance for overhead cranes or forklifts without ever relocating the rack itself. Starting at $6,200 and customizable to the millimeter, each unit arrives CE-, UE-, and ISO 9001-certified, ready to anchor the most demanding workshop environments on the planet.
Built Around Your Workflow, Not the Other Way Around
Traditional cantilever racks force operators to reach, lift, and pivot in tight quarters. Herochu reverses that paradigm. By integrating a precision-machined crank mechanism into every arm, the rack extends outward like a drawer, suspending the load in mid-air where a single operator can rotate, inspect, or stage it for downstream processes. When the job is complete, the arms glide back into the frame, shrinking the footprint by up to 65 % and restoring clear sightlines across the facility. Whether you configure a single-sided wall unit or a double-sided island, three roll-out tiers plus a fixed top level create a graduated storage matrix that keeps high-velocity SKUs at waist height and reserve stock overhead.
Proven in the Field, Polished for Your Standards
Herochu has delivered hundreds of roll-out cantilever projects across five continents. Each system is stress-tested to 125 % of rated capacity, then powder-coated in a high-gloss, scratch-resistant finish that stands up to weld spatter, forklift bumps, and caustic wash-down cycles. The modular uprights accept bolt-on accessories—dividers, end-stops, fork entry bars—so the rack evolves with your product mix instead of becoming obsolete. Manual crank models ship with a sealed planetary gearbox rated for 50,000 cycles; electric-assist variants include a soft-start motor, emergency-stop pendant, and optional integration with your warehouse management system.
Specifications That Speak to Serious Loads
Model HC-G6053D
Load per layer: 3 t
Pipe length accommodated: 6 m
Configuration: 4 roll-out layers + 1 fixed, double-sided
Overall footprint: 6,435 mm L × 3,340 mm W × 1,750 mm H
Model HC-G9055S
Load per layer: 5 t
Pipe length accommodated: 9 m
Configuration: 4 roll-out layers + 1 fixed, single-sided
Overall footprint: 9,435 mm L × 3,340 mm W × 1,550 mm H
Model HC-G9055D
Load per layer: 5 t
Pipe length accommodated: 9 m
Configuration: 4 roll-out layers + 1 fixed, double-sided
Overall footprint: 9,435 mm L × 3,340 mm W × 1,750 mm H
Model HC-G12055D
Load per layer: 5 t
Pipe length accommodated: 12 m
Configuration: 4 roll-out layers + 1 fixed, double-sided
Overall footprint: 12,435 mm L × 3,340 mm W × 1,750 mm H
Every dimension, load rating, and tier count can be engineered to order. Specify arm spacing in 100 mm increments, choose galvanized or stainless steel for corrosive environments, or add RFID locator tabs for perpetual inventory accuracy.
Space, Safety, Speed—Pick All Three
- Space Saving: By eliminating the fixed aisles required by conventional cantilever systems, Herochu frees up to 40 % of floor area that can be repurposed for value-added operations or additional inventory.
- Efficiency Gains: One technician can load or unload a 5-ton bundle in under two minutes, slashing labor hours and crane wait times.
- Safety First: Extended arms place the load at an ergonomic height, reducing back strain, while the retracted position removes trip hazards and improves forklift sightlines. A mechanical lock secures every arm in both the open and closed states, ensuring zero drift during transport or seismic events.
From Quote to Commissioning in Six Weeks
Herochu’s in-house engineering team converts your CAD layout or hand sketch into a signed approval drawing within 72 hours. Fabrication, surface treatment, and pre-assembly occur in our ISO 9001-certified facility, followed by full-load testing and laser-verified dimensional checks. Systems ship knock-down to minimize freight cost, yet every bolt hole is pre-drilled and every weld pre-inspected, so on-site assembly typically takes a two-person crew less than one shift.
Invest Once, Profit for Decades
At $6,200 for a base configuration, the Herochu crank-out cantilever warehouse rack pays for itself in the first year through reclaimed floor space, reduced handling labor, and fewer product damage claims. Ten-year structural warranty, lifetime technical support, and global spare-parts inventory protect that investment well into the next decade.
Stop wrestling with haphazard pipe piles and start commanding a storage system that works as hard as you do. Contact Herochu today for a same-day layout proposal and see why industry leaders specify our crank-out cantilever racks when only the strongest, smartest, and most space-efficient solution will do.
